Flame Retardant HDT

From: 48,95

Liqcreate Flame Retardant HDT is a rigid off-white photopolymer 3D-printing resin with a high temperature resistance (HDT-B upto 257°C / 495°F) and can be processed on most open Digital Light Processing (DLP), Liquid Crystal Display (LCD/MSLA) and laser based 3D-printers. 3D-printed parts from this material can withstand high temperatures without posing a fire hazard due to its self-extinguishing capabilities (UL94 V0 at 3 mm). The material is designed for creating parts that need comply with UL94-V0 test standards, such as parts for car interior, railway, aviation and electronics. In addition, it can be excellent for tooling manufacturing aids, connector housings and covers. Caution! This resin has a strong adhesion to build plates, read instructions before using.

Scroll down to: Technical specifications | Printer compatibilityUse casesProcessing instructions



High temperature resistant sla dlp 3D printer resin

Flame Retardant resin

UL94-V0 Rating at 3mm

High temperature resistance



EAN: N/A SKU: N/A
Clear

Technical specifications

Liqcreate Flame Retardant HDT is a rigid off-white photopolymer 3D-printing resin and can be processed on most open resin based 3D-printers. 3D-printed parts from this material can withstand high temperatures (HDT-B upto 257°C / 495°F) without posing a fire hazard due to its self-extinguishing capabilities. The material is perfect for creating parts that need comply with UL94 V0 test standards, such as parts for car interior, railway, airplane and electronics. In addition, it can be excellent for tooling manufacturing aids, connector housings and covers.

Polymer properties
Mechanical Properties
Description Method UV curing 60 minutes at 60°C[1] UV curing 120 minutes at 60°C[1]
Tensile strength D638 41 MPa 43 MPa
Tensile modulus D638 4.2 GPa 4.2 GPA
Elongation at break D638 1 – 3% 1 – 3%
Flexural strength D790 73 MPa 67 MPa
Flexural modulus D790 4.3 GPa 4.4 GPa
IZOD Impact (notched) D256A 13 J/m 13 J/m
IZOD Impact (notched) ISO 180 1,74 kJ/m2 1,85 kJ/m2
Water sorption D570-98 0.41%  0.41%
Shore D Hardness D2240 88 89
HDT-B 0.45 MPa ISO75 237°C / 459°F 257°C / 495°F
HDT-A 1.8 MPa ISO75 137°C / 279°F 145°C / 293°F
Degradation temperature Internal method > 250°C2/482°F[2] > 250°C2/482°F[2]
Flamability UL94 V0 3,0 mm 3,0 mm
Far 25.853 – Appendix F, Part I (a) (1) (ii)12 seconds Vertical Burn Internal method 1,5 mm 1,5 mm

[1]Post-cured 60 minutes and 120 minutes with high power LED curing at 60°C in the Wicked Engineering curebox. Values and material properties may vary and depend on individual machine processing, part geometry, print orientation, print settings and post-curing settings. [2] Discoloration Above 200°C.

tilt screen

Tilt screen to see the complete technical specifications table

Excellent HDT and Flame Retardant UL94 V0 properties

Liqcreate Flame Retardant HDT has a high heat deflection temperature (HDT) while maintining its excellent UL94 V0 self extinguishing flame retardant properties.

Liqcreate HDT vs Modulus Flame Retardant HDT graph 10-2023

Liquid Properties
Description Value
Appearance White liquid
Viscosity 2800 mPa.s at 25°C
Density 1.12 g/cm3
Ec (405nm) 6.25 mJ/cm2
Dp (405nm) 0.234 mm
Ec (385nm) 3.11 mJ/cm2
Dp (385nm) 0.095 mm

More information

Values of Liqcreate Flame Retardant HDT resin may vary and depend on individual machine processing and post-curing. For extra details, download the technical data sheet or user guide.

Technical Data Sheet   ⤓ Processing instructions   ⤓ User Guide

Need support?

Processing instructions

New to resin 3D-printing, or a seasoned professional, it is advised to scroll through the Liqcreate Flame Retardant HDT (UL94 V0) resin processing instructions. Detailed information on printing parameters, support settings, cleaning, washing, post-curing, part orientation, shrinkage compensation, minimum wall thickness and other resin behaviour can be found in the link.

Hazard statements on CLP product label
H315: Causes skin irritation.
H317: May cause an allergic skin reaction.
H318: Causes serious eye damage
H410: Very toxic to aquatic life with long lasting effects.

3D Printer compatibility

Do you want to use Flame Retardant HDT resin? Check if settings for this UL94 V0 resin are available on our website for your printer!

Printer name Compatible?
Nexa3D XiP Yes (open license)
W2P SolFlex 150 Yes
W2P SolFlex 163 Yes
W2P SolFlex 170 Yes
W2P SolFlex 250 Yes
W2P SolFlex 350 Yes
W2P SolFlex 650 Yes
Shining3D AccuFab-L4K Yes
Asiga Max UV Yes
Asiga Pro 4K Yes
Anycubic Photon Mono Yes
Anycubic Photon Mono SE Yes
Anycubic Photon Mono X Yes
Anycubic Photon M3 Yes
Anycubic Photon M3 Plus Yes
Anycubic Photon D2 Yes
Peopoly Phenom Prime Yes
Creality Halot-One Yes
Elegoo Mars 2 Yes
Elegoo Mars 2 Pro Yes
Elegoo Mars 3 Yes
Elegoo Saturn Yes
Elegoo Saturn 3 Yes
Phrozen Sonic Mini 4K Yes
Phrozen Sonic Mini 8K Yes
385 – 420nm MSLA, SLA & DLP printer Contact us

Flame Retardant HDT use cases

Liqcreate Flame Retardant HDT is perfect for applications that require UL94 V0 materials, for instance in electronics, aviation, automobiles, and the railway industry.

Liqcreate Flame Retardant HDT RGB use case1 web
Weight N/A
Printer compatibility

SLA, DLP, LCD
